Features
Can be used with fittings with replaceable remote driver.
220÷240 V 50/60 Hz
Lifetime 50000 h.
Characteristic data
Dimensional characteristics
Electrical characteristics
Operating temperature
-25°C / +45°C
LED Warranty
G5h24
Full Guarantee
5 years
(24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61347-1:2016 (+A1:2021)
CEI EN 61347-2-13:2015 (+A1:2018)
CEI EN 61547:2010
Logistics data
Barcode single item
8011905990565
Product sheet
Tender text
Extended
Compact
ZKLP1400-EL - Constant current driver
Features
Can be used with fittings with replaceable remote driver.
220÷240 V 50/60 Hz
Lifetime 50000 h.
Characteristic data
Power: 60 W
Dimmable: No
Input: 220-240 Vac
Base: Screws
IP: 20
PF: 0,95
LED Warranty: G5h24
Dimensional characteristics
Dimensiones
L: 156 mm
L1: 50 mm
H: 38 mm
Electrical characteristics
Rated power: 60 W
Input voltage: 220-240 Vac
Dimmable: No
Power factor (PF): 0,95
Operating temperature: -25°C / +45°C
LED Warranty
G5h24: Full Guarantee
5 years
(24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61347-1:2016 (+A1:2021)
CEI EN 61347-2-13:2015 (+A1:2018)
CEI EN 61547:2010
Logistics data
Item net weight: 95 gr
Barcode single item: 8011905990565
Minimum order quantity: 1
Minimum packaging: 1 / 1
ZKLP1400-EL - Constant current driver
Features: Can be used with fittings with replaceable remote driver. 220÷240 V 50/60 Hz Lifetime 50000 h. Characteristic data - Power: 60 W; Dimmable: No; Input: 220-240 Vac; Base: Screws; IP: 20; PF: 0,95; LED Warranty: G5h24. Dimensional characteristics - Dimensiones; L: 156 mm; L1: 50 mm; H: 38 mm. Electrical characteristics - Rated power: 60 W; Input voltage: 220-240 Vac; Dimmable: No; Power factor (PF): 0,95; Operating temperature: -25°C / +45°C. LED Warranty - G5h24: Full Guarantee ; 5 years ; (24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions. European Directives - 2009/125/EC * Ecodesign; 2011/65/EU * RoHS; 2012/19/EU * RAEE; 2014/30/EU * EMC; 2014/35/EU * LVD; 2015/863 * Amending RoHS; 2017/1369 * Regulation for Energy Labelling; 2019/2015 * Regulation for Energy Labelling; 2019/2020 * Regulation for Ecodesign; 2021/340 * Amending Reg. Energy Labelling; 2021/341 * Amending Reg. Ecodesign. Product standards - CEI EN 55015:2020 (+A11:2020); CEI EN 61000-3-2:2019 (+A1:2021); CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022); CEI EN 61347-1:2016 (+A1:2021); CEI EN 61347-2-13:2015 (+A1:2018); CEI EN 61547:2010. Logistics data - Item net weight: 95 gr; Barcode single item: 8011905990565; Minimum order quantity: 1; Minimum packaging: 1 / 1.
