Typology
Super-compact professional projectors for large commercial and industrial spaces; uses highly efficient SMD technology, up to 175lm/W.
Features
Ultra-flat, highly efficient, long service life: reliable products for use in all areas where powerful light output with significant energy savings is required.
Equipped with voltage surge protection, see details.
Installation
Free-standing or fixed to the surface with its swivelling bracket.
Cable lenght: 30 cm
Material
Die-cast aluminium body.
Suitable for use in dusty and humid environments due to its high IP rating.
Usage information
Fixtures suitable for installation and use in residential, commercial and light industrial environments, in systems with “Category I” of impulse withstand in compliance with CEI EN 64-8 / 4 (IEC 60364-4-44).
Beam
Symmetrical beam angle: 110°.
Characteristic data
Dimensional characteristics
Lighting and photometric features
CCT nominal colour temperature
3000 K
Colour of the light
Natural light
Electrical characteristics
Weighted energy consumption
24 kWh/1000h
Operating temperature
-25°C / +35°C
Other Infotech
LED Warranty
G5h24
Full Guarantee
5 years
(24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 60598-1:2022
CEI EN 60598-2-5:2016
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61547:2010
CEI EN 62031:2021 (+A11:2022)
CEI EN 62471:2010
IEC/TR 62471-2:2009
CEI EN 62493:2015
CEI 34-141:2014
Logistics data
Barcode single item
8011905326722
Number of pieces multiple pack
20
Product sheet
Tender text
Extended
Compact
PAH1L04BLW - PANTH H1
Typology
Super-compact professional projectors for large commercial and industrial spaces; uses highly efficient SMD technology, up to 175lm/W.
Features
Ultra-flat, highly efficient, long service life: reliable products for use in all areas where powerful light output with significant energy savings is required.
Equipped with voltage surge protection, see details.
Installation
Free-standing or fixed to the surface with its swivelling bracket.
Cable lenght: 30 cm
Material
Die-cast aluminium body.
Suitable for use in dusty and humid environments due to its high IP rating.
Usage information
Fixtures suitable for installation and use in residential, commercial and light industrial environments, in systems with “Category I” of impulse withstand in compliance with CEI EN 64-8 / 4 (IEC 60364-4-44).
Beam
Symmetrical beam angle: 110°.
Characteristic data
Power: 24 W
Beam: 110°
Dimmable: No
Input: 220-240 Vac
Base: Free terminals
IP: 65
Flux: 3900 lm
PF: 0.5
Tc: 3000 K
Ra: 80
LED Warranty: G5h24
Axis: 1450 cd
IK: IK04
RG: RG1
Color: Black
Dimensional characteristics
Dimensiones
L: 145 mm
L1: 105 mm
H: 29 mm
Lighting and photometric features
Beam opening: 110°
Flux: 3900 lm
CCT nominal colour temperature: 3000 K
Colour of the light: Natural light
Colour rendering index: 80
Lifespan: 50000 h
LED lifespan: L70B20
Electrical characteristics
Rated power: 24 W
Input voltage: 220-240 Vac
Frequency: 50-60 Hz
Dimmable: No
Power factor (PF): 0.5
Input current: 0.29 A
Weighted energy consumption: 24 kWh/1000h
Operating temperature: -25°C / +35°C
LED Warranty
G5h24: Full Guarantee
5 years
(24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 60598-1:2022
CEI EN 60598-2-5:2016
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61547:2010
CEI EN 62031:2021 (+A11:2022)
CEI EN 62471:2010
IEC/TR 62471-2:2009
CEI EN 62493:2015
CEI 34-141:2014
Logistics data
Item net weight: 324 gr
Barcode single item: 8011905326722
Number of pieces multiple pack: 20
Minimum order quantity: 1
Minimum packaging: 1 / 20
Other Infotech
Flicker Free: Yes
PAH1L04BLW - PANTH H1
Typology: Super-compact professional projectors for large commercial and industrial spaces; uses highly efficient SMD technology, up to 175lm/W. Features: Ultra-flat, highly efficient, long service life: reliable products for use in all areas where powerful light output with significant energy savings is required. Equipped with voltage surge protection, see details. Installation: Free-standing or fixed to the surface with its swivelling bracket. Cable lenght: 30 cm Material: Die-cast aluminium body. Suitable for use in dusty and humid environments due to its high IP rating. Usage information: Fixtures suitable for installation and use in residential, commercial and light industrial environments, in systems with “Category I” of impulse withstand in compliance with CEI EN 64-8 / 4 (IEC 60364-4-44). Beam: Symmetrical beam angle: 110°. Characteristic data - Power: 24 W; Beam: 110°; Dimmable: No; Input: 220-240 Vac; Base: Free terminals; IP: 65; Flux: 3900 lm; PF: 0.5; Tc: 3000 K; Ra: 80; LED Warranty: G5h24; Axis: 1450 cd; IK: IK04; RG: RG1; Color: Black. Dimensional characteristics - Dimensiones; L: 145 mm; L1: 105 mm; H: 29 mm. Lighting and photometric features - Beam opening: 110°; Flux: 3900 lm; CCT nominal colour temperature: 3000 K; Colour of the light: Natural light; Colour rendering index: 80; Lifespan: 50000 h; LED lifespan: L70B20. Electrical characteristics - Rated power: 24 W; Input voltage: 220-240 Vac; Frequency: 50-60 Hz; Dimmable: No; Power factor (PF): 0.5; Input current: 0.29 A; Weighted energy consumption: 24 kWh/1000h; Operating temperature: -25°C / +35°C. LED Warranty - G5h24: Full Guarantee ; 5 years ; (24h/24h) Without limitations on the duration of use for the first year, provided the observance of the installation conditions. European Directives - 2009/125/EC * Ecodesign; 2011/65/EU * RoHS; 2012/19/EU * RAEE; 2014/30/EU * EMC; 2014/35/EU * LVD; 2015/863 * Amending RoHS; 2017/1369 * Regulation for Energy Labelling; 2019/2015 * Regulation for Energy Labelling; 2019/2020 * Regulation for Ecodesign; 2021/340 * Amending Reg. Energy Labelling; 2021/341 * Amending Reg. Ecodesign. Product standards - CEI EN 55015:2020 (+A11:2020); CEI EN 60598-1:2022; CEI EN 60598-2-5:2016; CEI EN 61000-3-2:2019 (+A1:2021); CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022); CEI EN 61547:2010; CEI EN 62031:2021 (+A11:2022); CEI EN 62471:2010; IEC/TR 62471-2:2009; CEI EN 62493:2015; CEI 34-141:2014. Logistics data - Item net weight: 324 gr; Barcode single item: 8011905326722; Number of pieces multiple pack: 20; Minimum order quantity: 1; Minimum packaging: 1 / 20. Other Infotech - Flicker Free: Yes.
