Typology
Transformers constant voltage output electronic LED power supply.
Notes
It is advisable not to charge the driver more than 55% of its power in order to consider the in-rush current of LED lamps.
Characteristic data
Dimensional characteristics
Electrical characteristics
Max output current
1670 mA
Operating temperature
-25°C / +35°C
LED Warranty
G2
Up to 2 years
(4000h/year) *4000h = 11h a day x 365 days.
Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61347-1:2016 (+A1:2021)
CEI EN 61347-2-13:2015 (+A1:2018)
CEI EN 61547:2010
Logistics data
Barcode single item
8011905834616
Product sheet
Tender text
Extended
Compact
DELT20A-12 - Electronic transformer
Typology
Transformers constant voltage output electronic LED power supply.
Notes
It is advisable not to charge the driver more than 55% of its power in order to consider the in-rush current of LED lamps.
Characteristic data
Power: 20 W
Dimmable: No
Input: 200-240 Vac
Base: Screws
IP: 20
LED Warranty: G2
Dimensional characteristics
Dimensiones
L: 154 mm
L1: 50 mm
H: 22 mm
Electrical characteristics
Rated power: 20 W
Input voltage: 200-240 Vac
Frequency: 50 Hz
Output voltage: 12 Vdc
Dimmable: No
Max output current: 1670 mA
Operating temperature: -25°C / +35°C
LED Warranty
G2: Up to 2 years
(4000h/year) *4000h = 11h a day x 365 days.
Without limitations on the duration of use for the first year, provided the observance of the installation conditions.
European Directives
2009/125/EC * Ecodesign
2011/65/EU * RoHS
2012/19/EU * RAEE
2014/30/EU * EMC
2014/35/EU * LVD
2015/863 * Amending RoHS
2017/1369 * Regulation for Energy Labelling
2019/2015 * Regulation for Energy Labelling
2019/2020 * Regulation for Ecodesign
2021/340 * Amending Reg. Energy Labelling
2021/341 * Amending Reg. Ecodesign
Product standards
CEI EN 55015:2020 (+A11:2020)
CEI EN 61000-3-2:2019 (+A1:2021)
CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022)
CEI EN 61347-1:2016 (+A1:2021)
CEI EN 61347-2-13:2015 (+A1:2018)
CEI EN 61547:2010
Logistics data
Item net weight: 90 gr
Barcode single item: 8011905834616
Minimum order quantity: 1
Minimum packaging: 1 / 1
DELT20A-12 - Electronic transformer
Typology: Transformers constant voltage output electronic LED power supply. Notes: It is advisable not to charge the driver more than 55% of its power in order to consider the in-rush current of LED lamps. Characteristic data - Power: 20 W; Dimmable: No; Input: 200-240 Vac; Base: Screws; IP: 20; LED Warranty: G2. Dimensional characteristics - Dimensiones; L: 154 mm; L1: 50 mm; H: 22 mm. Electrical characteristics - Rated power: 20 W; Input voltage: 200-240 Vac; Frequency: 50 Hz; Output voltage: 12 Vdc; Dimmable: No; Max output current: 1670 mA; Operating temperature: -25°C / +35°C. LED Warranty - G2: Up to 2 years ; (4000h/year) *4000h = 11h a day x 365 days. ; Without limitations on the duration of use for the first year, provided the observance of the installation conditions. European Directives - 2009/125/EC * Ecodesign; 2011/65/EU * RoHS; 2012/19/EU * RAEE; 2014/30/EU * EMC; 2014/35/EU * LVD; 2015/863 * Amending RoHS; 2017/1369 * Regulation for Energy Labelling; 2019/2015 * Regulation for Energy Labelling; 2019/2020 * Regulation for Ecodesign; 2021/340 * Amending Reg. Energy Labelling; 2021/341 * Amending Reg. Ecodesign. Product standards - CEI EN 55015:2020 (+A11:2020); CEI EN 61000-3-2:2019 (+A1:2021); CEI EN 61000-3-3:2014 (+EC1:2014/+EC2:2016/+A1:2021/+A2:2022); CEI EN 61347-1:2016 (+A1:2021); CEI EN 61347-2-13:2015 (+A1:2018); CEI EN 61547:2010. Logistics data - Item net weight: 90 gr; Barcode single item: 8011905834616; Minimum order quantity: 1; Minimum packaging: 1 / 1.
